SPECIFICATIONS

Brand Name: IGOLDENCNC

Origin: Mainland China

Type: Universal

Condition: New

Model Number: iGW-MF

Range of Spindle Speed(r.p.m): 1 – 24000

Number of Axes: 4

No. of Spindles: Single

Machining Capacity: Light Duty

Spindle Taper: Other

Table Travel (X) (mm): 1000

Table Travel (Y) (mm): 800

Table Travel (Z) (mm): 360

Positioning Accuracy (mm): ±0.02

Repeatability (X/Y/Z) (mm): ±0.01

Table Travel (mm): 600*600*250mm

Year: 2023

Voltage: 380v/50HZ

Dimension(L*W*H): 1687*1860*1860mm

Key Selling Points: Flexible Manufacturing

Weight (KG): 100

Spindle Motor Power(kW): 7.5KW

Warranty: 1 Year

Max. Table Load(kg): 600 kg

Marketing Type: Ordinary Product

Machinery Test Report: Provided

Body: Cast iron bed + welded support

spindle: Water cooled automatic tool change spindle

Table: Cast iron removable countertop

Guide rail: TAIWAN HIWIN

Screw: TAIWAN TBI

Drive: Yaskawa servo motor

Reducer: SHIMPO

Electrical element: SCHNEIDER

lubrication system: Automatic oil filling

3d cnc router metal milling aluminium alloy engraving and making machine Professional Manufacturer

Product Description

Product Paramenters

Model	iGW-MF
Working area	600*600*260mm
Bed	Heavy cast iron
Spindle	7.5KW ATC water cooling spindle
Magazine tool	Circle tools magazine
Inverter	Fuling
Motor	Japan servo yaskawa
Control system	LNC
Oiling	Automatic
Table	Heavy duty cast iron countertop
Transmission	TAIWAN HIWIN guide rail TBI screw
Voltage	3phase 380V/50HZ

Details Images

Samples

About US

Packaging and Shipping

FAQ

Q: How to install and maintain the machine?
A: Before you use it, we will send the operation tutorial and installation operation video with an English version to you. If you still can not operate, we will provide video guidance online.

Q: What are the machine working environment requirements?
A: The machine should be fixed on a stable table and the environment should be kept clean and tidy to avoid contact with dust, static electricity, humidity, and chips to cause parts failure.

Q: Can you arrange the shipment for me ?
A: Yes, of course we can. Our products have been shipped to dozens of countries and regions in the world, and we are very
experienced. You can tell us the nearest port to you and the dedicated manager will check the freight for you and help you handle subsequent transportation.
